GCSE Physics equations

Every equation on the GCSE Science Pack's physics sheets, in words and symbols, with its units.

By Brainlag

Free

Add to my Brainlag Flashcards Download for Anki Download CSV

No account needed.

Try five cards

1 / 5

Tap the card to turn it over.

Details

Cards
35
Who it is for
GCSE students (Years 10 and 11)
Works with
Brainlag Flashcards, Anki, any spreadsheet
Language
English
File size
4 KB (Anki)

How to use

The deck is copied into Flashcards on this device, with spaced repetition. No account needed.

Anki: File, Import, then choose the file. It makes the deck and tags the cards for you.

Licence

Personal and classroom use. Teachers can share it with their own classes. Please do not resell it.

Questions

Write to us at [email protected].

Cancelling and refunds

Pairs well with

See the cards (35)
Weight
W = mg, weight (N) = mass (kg) × gravitational field strength (N/kg)
Work done
W = Fs, work done (J) = force (N) × distance moved along the line of the force (m)
Force on a spring
F = ke, force (N) = spring constant (N/m) × extension (m)
Moment of a force (physics only)
M = Fd, moment (N m) = force (N) × perpendicular distance to the pivot (m)
Pressure (physics only)
p = F / A, pressure (Pa) = force normal to the surface (N) ÷ area of the surface (m²)
Distance travelled
s = vt, distance travelled (m) = speed (m/s) × time (s)
Acceleration
a = Δv / t, acceleration (m/s²) = change in velocity (m/s) ÷ time (s)
Resultant force
F = ma, resultant force (N) = mass (kg) × acceleration (m/s²)
Show all 35
Momentum (HT)
p = mv, momentum (kg m/s) = mass (kg) × velocity (m/s)
Kinetic energy
Eₖ = ½mv², kinetic energy (J) = ½ × mass (kg) × speed² (speed in m/s)
Gravitational potential energy
Eₚ = mgh, gravitational potential energy (J) = mass (kg) × gravitational field strength (N/kg) × height (m)
Power, from energy and time
P = E / t, power (W) = energy transferred (J) ÷ time (s)
Power, from work done and time
P = W / t, power (W) = work done (J) ÷ time (s)
Efficiency, from energy
Efficiency = useful output energy (J) ÷ total input energy (J). Efficiency has no unit; multiply by 100 for a percentage.
Efficiency, from power
Efficiency = useful power output (W) ÷ total power input (W). Efficiency has no unit; multiply by 100 for a percentage.
Wave speed
v = fλ, wave speed (m/s) = frequency (Hz) × wavelength (m)
Charge flow
Q = It, charge flow (C) = current (A) × time (s)
Potential difference
V = IR, potential difference (V) = current (A) × resistance (Ω)
Power, from potential difference and current
P = VI, power (W) = potential difference (V) × current (A)
Power, from current and resistance
P = I²R, power (W) = current² (current in A) × resistance (Ω)
Energy transferred, from power and time
E = Pt, energy transferred (J) = power (W) × time (s)
Energy transferred, from charge and potential difference
E = QV, energy transferred (J) = charge flow (C) × potential difference (V)
Density
ρ = m / V, density (kg/m³) = mass (kg) ÷ volume (m³)
Motion with a steady acceleration
v² − u² = 2as, final velocity² (final velocity in m/s) − initial velocity² (initial velocity in m/s) = 2 × acceleration (m/s²) × distance (m)
Force and momentum (physics only, HT)
F = mΔv / Δt, force (N) = mass (kg) × change in velocity (m/s) ÷ time taken (s)
Elastic potential energy
Eₑ = ½ke², elastic potential energy (J) = ½ × spring constant (N/m) × extension² (extension in m). This holds while the limit of proportionality is not passed.
Specific heat capacity
ΔE = mcΔθ, change in thermal energy (J) = mass (kg) × specific heat capacity (J/kg °C) × temperature change (°C)
Specific latent heat
E = mL, thermal energy for a change of state (J) = mass (kg) × specific latent heat (J/kg)
Period
T = 1 / f, period (s) = 1 ÷ frequency (Hz)
Magnification of a lens (physics only)
Magnification = image height ÷ object height. No unit: measure both heights in the same unit, such as mm.
Force on a conductor (HT)
F = BIl, force (N) = magnetic flux density (T) × current (A) × length of conductor in the field (m). The conductor is at right angles to the field.
Transformers (physics only, HT)
VₚIₚ = VₛIₛ, primary potential difference (V) × primary current (A) = secondary potential difference (V) × secondary current (A)
Turns ratio (physics only, HT)
Vₚ / Vₛ = nₚ / nₛ, primary potential difference (V) ÷ secondary potential difference (V) = primary turns ÷ secondary turns
Pressure in a liquid (physics only, HT)
p = hρg, pressure (Pa) = height of the column (m) × density (kg/m³) × gravitational field strength (N/kg)
Gas at constant temperature (physics only)
pV = constant, pressure (Pa) × volume (m³) = constant. For a fixed mass of gas.
